Features
power LED-array based light irradiator, fan-cooled
fully software controlled (power, irradiation time, mixing ratios - if applicable)
within a measurement sequence the settings can be varied
special optics for uniform irradiation power at the sample
bleaching is possible at elevated temperatures
LED-based bleaching/Solar simulation unit
wavelengths: 365 nm, 462 nm, 523 nm, 590 nm, 625nm, 850 nm
can be used for monochromatic sample irradiation or individually mixed for simulation of variousbleaching conditions
typical maximum optical power at the sample: UV 365 nm : 65 mW
RGB A 462 nm : 140 mW, 523 nm : 35 mW, 590 nm : 50 mW, 625 nm : 85 mW; IR 850 nm: 170 mWpower regulation loop for each light channel
display of bleaching light spectrum
